7 inch Truck DVR

---

Key Specifications/ Special Features:

Product Name

Multifunctional 7inch 4 camera 4 parking sensor 360   degree hard disk DVR for truck/bus/ construction machinery

Function

Blind spots significantly contribute to vehicle   collisions across industries, often caused by the size and design of vehicles   that restrict driver visibility. Features like elevated cabs, long bodies,   and blocked rear views worsen the issue. Our advanced on-road and off-road   safety solutions help eliminate blind spots, prevent costly accidents, and   save lives. With top-quality cameras, monitors, sensors, and audible alarms,   we offer customizable systems that improve safety, meet FORS/CLOCS compliance,   and provide crucial evidence in the event of incidents or claims.

AHD car camera:

* Sensitive components : 1/4 inch OV9712* Viewing angle: Real 150 degrees* Effective pixels : 1280×960P* Signal format: PAL/NTSC* Image horizontal resolution: 130W pixels* Video output: AHD VIDEO (960P)* Night Vision: Starlight Night Vision. The visible distance is greater than 20 meters.* Night Vision Image : Automatic Gain Control, Auto White Balance, Auto Backlight Compensation .* Exposure method: PAL: 1/50~/100000 seconds NTSC: 1/60~1/10000 seconds can be set* Lens : 14/16MM * Low illumination: o.01Lux* Signal to noise ratio: ≥69dB* Working power supply: DC12V/2A* Working temperature: -20 ° C ~ +50 ° C* Maximum power: 3W

Mobile DVR features & specification:

1/Language support: Portuguese, Chinese, English, French, Russian, Turkish

2/use H.264Video compression format,Hisilicon3520DV200 chip.

3/Software is powerful,MDVR chip and camera use Double Circuit Power Supply,The system is more secure and stable.

4/4ch video in use aviation port,VGA+CVBS video output,

5/1ch audio input ,1audio output.

6/1 VGA output ,1 CVBS output.

7/support one SD card slot (SD max support 256GB).

8/ACC Ignition start and delay shutdown

9/4Channel screen can menu to adjust left and right and up and down switch,menu set PAL and NTSC format.

10/4 ch switch alarm input(Optional Accessories).

11/Wide power input DC10-36V, adapted to automobile voltage fluctuation.
